Auto-drumfilter with tank (HDPE)

The fully automatic rotary drum filter, made with advanced German technology, is a low-energy mechanical filtration device. It quickly and efficiently removes suspended particles, uneaten feed, and fish waste from the water through a fine filter mesh. The waste is then discharged through a drain pipe. This filter can work together with other equipment to complete the water treatment process in a recirculating aquaculture system.

Category:

Physical Filtration System

Kingto

TEL：

0512-62518202

MESSAGES

Product Details



SPECIFICATIONS

Model

HDF20

HDF40

HDF60

HDF100

HDF150

HDF200

Filter  area(m²)

0.32

0.52

0.86

0.9

1.8

2.7

No.of fiter panels

4

4

4

2

4

6

Motor effect at 50Hz(K)

0.15

0.15

0.15

0.15

0.15

0.15

Voltage of motor

DC 24V

DC 24V

DC 24V

DC 24V

DC 24V

DC 24V

Pump effect at 50Hz(KW)

0.75

0.75

0.75

0.75

1.1

1.1

Voltage of pump

AC 220V

AC 220V

AC 220V

AC 220V

AC 220V

AC 220V

Rinsing at 7bar(Ls)

0.2

0.2

0.3

0.3

0.5

0.8

No.of nozzles (pcs)

4

4

6

5

10

15

Inlet /outlet(mm)

160

160

200

250

315

355

Sludge outlet(mm)

110

110

110

110

110

110

Tank,lid and drum material

HDPE

HDPE

HDPE

HDPE

HDPE

HDPE

Filter dimensions(mm)

Length:991
Width:996
Height 842

Length:1070
Width:1064
Height:842

Length:842
Width:1921
Height 1222

Length:1260
Width:1313
Height:1075

Length:1670
Width:1313
Height:1075

Length:2122
Width:1313
Height 1075

Net weight (kg)

83

111

161

182

202

300



CAPACITY(M³/H)TABLE

Filtration accuracy

Mesh size

HDF20

HDF40

HDF60

HDF100

HDF150

HDF200

RAS<15℃
SS<25mgL

30μm

17

29

54

62

117

175

40μm

22

38

71

82

154

230

60μm

30

49

77

120

191

243

RAS<20℃
SS<25mg/L

75μm

35

49

77

120

191

243

30μm

16

28

52

60

112

188

40μm

20

35

65

75

140

209

60μm

28

47

77

112

190

243

  RAS<25℃
  SS<25mg/L

75μm

32

49

77

120

191

243

30μm

15

26

47

55

103

154

40μm

19

33

61

71

133

198

60μm

26

44

73

106

180

230

75μm

30

49

77

120

191

243
