Auto-drumfilter with frame (Stainless Steel)

The fully automatic rotary drum filter, made with advanced German technology, is a low-energy mechanical filtration device. It quickly and efficiently removes suspended particles, uneaten feed, and fish waste from the water through a fine filter mesh.The waste is then discharged through a drain pipe. This filter can work together with other equipment to complete the water treatment process in a recirculating aquaculture system.

Category:

Physical Filtration System

TEL：

0512-62518202

MESSAGES

Product Details

SPECIFICATIONS

Model		KDF-801	KDF-802	KDF-803	KDF-804	KDF-1201	KDF-1202	KDF-1203	KDF-1204	KDF-1205	KDF-1602	KDF-1603	KDF-1604	KDF-1605	KDF-1606	KDF-1607
No.of fiter panels		2	4	6	8	3	6	9	12	15	8	12	16	20	24	28
Filter area(m²)		0.9	1.8	2.7	3.6	1.35	2.7	4.05	54	6.75	3.6	5.4	72	9	10.8	12.6
Effective fitration area by immersion(m²)		0.51	102	1.53	2.04	0.80	1.60	2.40	320	4.00	236	3.54	4.72	5.90	7.07	825
Percentage of immersion		56.60%				59.30%			65.5%
	10μm	15	29	44	59	23	46	69	92	115	68	102	135	169	203	237
	20um	31	61	92	122	48B	96	144	192	240	141	212	282	353	424	494
Capacity(m²/h)	30μm	50	99	149	199	78	156	234	313	391	230	345	460	576	691	806
RAS<25C SS<25mg/L	40um	61	123	184	246	97	193	290	386	483	284	427	569	711	853	1354
	60um	84	167	251	334	131	263	394	525	657	387	580	774	967	1161	1354
	75um	96	191	287	383	150	301	451	602	752	443	665	886	1108	1329	1354
SEW Gearmotors	Motor voltage	Three-phase AC380V				Three-phaseAC380V		Three-phase AC380V			Three-phase AC380V
	Motor power 50Hz(KW)	0.25				0.37		0.37			0.55
	Torque (nm)	101				215		215			375
	Speed r/min	15				10		10			9.1
	Waterpoof rating	IP55				IP55		IP55			IP55
Y fiter interface		314”				3/4”		3/4”			314”
Drain pipe diameter (mm)		φ110				φ110		φ110			φ110
Immersion vertical pumps	Power (kw)	1.1	1.1	1.5	2.2	1.1	1.1	1.5	2.2	22	1.1	1.5	22	22	3	3
	Lift (m)	90.5	85.9	85.9	90.5	90.5	85.9	85.9	90.5	90	85.9	85.9	90.5	90	94	89
	Flow(m²/h)	0.91	1.77	265	3.6	0.91	1.77	2.65	3.6	4.5	1.77	2.65	3.6	4.5	5.5	6.2
	Rated Voltage(V)	Three-phase AC380V
Overall dimension L×W×H(mm)		1023×978×1134	1458×978×1134	1868×978×1134	2278×978×1134	1043×1380×1488	1478×1380×1488	1888×1380×1488	2298×1380×1488	2708×1380×1488	1662×1880×1982	2017×1880×1932	2482×1880×1982	2892×1880×19323	3302×1880×1932	3712×1880×1932
Weight (KG)		246	281	315	345	350	410	440	500	246	724	802	902	1001	1080	1161
