Moving Bed Biological Reactor(MBBR)

By adding a measured amount of suspended carriers (such as K5 media) into the reactor, the number and variety of microbes in the MBBR grow a lot. This helps the system treat water better. The carriers keep moving and bumping into each other in the water. This breaks big air bubbles into smaller ones, which helps oxygen spread better.<br> Each carrier has different types of microbes: anaerobic or facultative bacteria grow inside, while aerobic bacteria live on the outside. This means each carrier works like a small bioreactor,where both nitrification and denitrification happen at the same time. This improves how well the system removes nitrogen and uses oxygen.and organic pollutants, boosting the overall treatment performance.

Category:

Biofiltration System

Kingto

TEL：

0512-62518202

MESSAGES

Product Details



SPECIFICATIONS

Model

MBBR-10

MBBR-15

MBBR-30

MBBR-60

MBBR-100

Maximum  flow(m³/h)

10

20

60

85

120

Tank diameter(mm)

900

1400

2200

2600

3200

Tank height(mm)

2500

2400

3000

3000

3000

Inlet diameter (mm)

110

110

160

250

315

Outlet diameter(mm)

110

110

160

250

315

Capacity for feed at 48%protein
@seawater @6-28°℃(kg/day)

6

6

6

6

6

K5 media with surface area 800m²/m³(m³)

0.6

1.7

5.1

7

11

Air  flow(m³/h)

10

20

40

60

85

Air pressure(mbar)

240

280

340

340

340

Outlet diameter of air blower(DN:mm)

32

40

50

50

80
