Fixed Bed Biological Reactor(FBBR)

The main function of a Fixed Bed Biological Reactor(FBBR) is to trap and remove fine particles from the water. It also helps clean the water by using helpful bacteria that grow on the surface of the media. These bacteria break down harmful substances like ammonia (NH3) and nitrite(NO2) through a process called nitrification, improving water quality and making it safer for fish and other aquatic life.

Category:

Biofiltration System

Kingto

TEL：

0512-62518202

MESSAGES

Product Details



SPECIFICATIONS

  Model

KFB-30

KFB-60

KFB-100

Dimension(mm)

1400x2400

2200x3000

2600x3000

Material

HDPE/PP

  Treatment  capacity(m³/h)

30

60

100

  Inlet pipe diameter(mm)

110

160

160

  Outlet pipe diameter (mm)

160

200

250

Note:Feed weight conversion reference 1L=0.68Kg
